Solving Pigment Settling in Stored Paint — A Raw Material Approach

Pigment settling is one of the most economically damaging defects in the paint distribution chain — particularly in the GCC, where warehouse temperatures routinely exceed 45°C in summer, dramatically accelerating sedimentation in stored products. When paint cakes at the bottom of a drum or can, it cannot be redispersed, resulting in product returns, customer complaints, and batch write-offs. This guide covers the raw material causes and solutions for pigment settling, from raw material selection to formulation optimisation.

Why Pigments Settle — The Physics

Pigment settling follows Stokes' Law: the settling rate is proportional to the square of the particle radius and the density difference between the pigment and the liquid medium, and inversely proportional to the viscosity of the medium. Practically, this means:

• Larger, denser pigment particles settle fastest (iron oxide, zinc dust, heavy calcium carbonate grades).
• Lower viscosity paint (e.g. due to high temperature) settles much faster — a paint at 45°C may settle 4× faster than at 25°C.
• Electrostatic repulsion between pigment particles (from dispersing agents) slows flocculation but cannot alone prevent settling of very dense particles.

Anti-Settling Raw Material Options

Anti-Settling Agent Type	Mechanism	Best For	Typical Usage %
Organobentonite (hectorite clay)	Forms a 3D gel network in solvent phase — provides true yield point to suspend particles	Solventborne systems, dense pigments (iron oxide, zinc), high-temperature storage	0.5–2.0%
Polyamide Wax Dispersion	Creates a thixotropic gel that flows under shear (application) but reforms at rest (storage)	Solventborne gloss/semi-gloss paints; balanced anti-sag and anti-settling	0.5–1.5%
HASE Thickener (alkali-swellable)	In waterborne systems: forms a loose network structure that suspends pigments at rest	Waterborne emulsion paints; latex coatings; water-based primers	0.2–0.8%
HEC (Hydroxyethyl Cellulose)	Increases aqueous phase viscosity at low shear rates, retarding sedimentation	Waterborne architectural paints; textured coatings	0.2–0.6%
Modified Castor Oil	Forms hydrogen-bonded network in aliphatic/aromatic solvents	Alkyd and epoxy systems; cost-effective for medium-density pigments	0.5–1.5%
Fumed Silica (treated)	Hydrogen bonding network; synergistic with bentonite for maximum anti-settling	Combined with bentonite for very dense pigments (zinc dust, heavy TiO2)	0.3–0.8%

The Role of Dispersing Agents

Anti-settling agents prevent the settled particles from caking — but dispersing agents prevent premature flocculation that accelerates settling. A poorly dispersed pigment with large flocculated aggregates settles much faster than a well-dispersed one. For GCC paints:

• Use a polymeric dispersant (phosphate ester or polyacrylate type) sized for your specific pigment surface chemistry.
• Ensure complete wetting of the pigment surface during the grind phase — insufficient dispersant or insufficient grind time leaves poorly wetted particles that flocculate rapidly during storage.
• For zinc-rich primers (which are particularly prone to hard settling), use a combination of organobentonite (0.8–1.2%) plus polyamide wax (0.5%) for maximum anti-settling performance in GCC warehouse conditions.

Formulation Tips for GCC Warehouse Storage (40–50°C)

• Increase organobentonite loading by 25–30% versus temperate-climate formulations to compensate for viscosity loss at high storage temperatures.
• Use high-gel-strength organobentonite (activation ratio 1:40 in aromatic solvent) — low-grade organobentonite loses effectiveness above 40°C.
• In waterborne systems, use a combination of HEC and HASE thickener — HEC provides storage stability, HASE provides in-can viscosity recovery after stirring.
• Consider adding a small amount of propylene glycol (1–2%) to waterborne systems to reduce the rate of viscosity loss at elevated temperatures.
• Test your formulation at 50°C for 4 weeks (accelerated storage test) before commercial launch in Saudi Arabia and UAE markets.

Sourcing Anti-Settling Raw Materials in the GCC

Raykem supplies a full range of paint additives and raw materials to manufacturers across the UAE and Saudi Arabia, including wetting and dispersing agents, thickeners, and anti-settling solutions for both solventborne and waterborne paint systems. Our solvent portfolio includes the aromatic solvents (Xylene, Aromatic 100) required for proper organobentonite activation. Contact our technical team for product recommendations tailored to your specific formulation and storage conditions.
