Formulating Low-VOC Textured Wall Coating for Saudi Residential Projects
Saudi Arabia's Vision 2030 housing programme — which targets the construction of over 300,000 new residential units — is driving unprecedented demand for interior and exterior wall coating materials. Increasingly, developers on projects like NEOM's The Line, Red Sea Project, and Qiddiya are specifying low-VOC, environmentally responsible coatings. This guide covers the complete raw material approach to formulating a low-VOC, water-based textured wall coating suitable for Saudi Arabia's climate and regulatory environment.
Regulatory note: GSO 1914 (applied across Gulf states including Saudi Arabia) limits VOC in interior flat wall coatings to 30 g/L. Any formulation for Vision 2030 projects should target sub-30 g/L VOC to meet specification and avoid compliance issues with SASO inspection.
Choosing the Right Binder System
The binder selection is the most important formulation decision for a low-VOC textured coating. For Saudi Arabia's climate:
- Pure Acrylic Emulsion (Tg 5–15°C): Best exterior performance. Excellent alkali resistance (important over fresh render), good UV stability, and superior crack-bridging ability. Higher cost but essential for exterior walls in harsh GCC conditions.
- Styrene-Acrylic Emulsion (Tg 10–20°C): Better balance of cost and performance. Good water resistance and scrub resistance. Suitable for interior and sheltered exterior applications. Widely used in Saudi residential projects.
- VAM/Veova Emulsion: Very cost-effective for interior matt applications. Good alkali resistance (Veova component). Not suitable for exterior in GCC climate due to relatively poor UV and water resistance compared to acrylic.
Complete Formulation — Low-VOC Textured Interior Wall Coating
| Raw Material | Function | % by Weight | Notes |
|---|---|---|---|
| Water | Continuous phase | 20–28% | Use deionised water where possible |
| Styrene-Acrylic Emulsion (50% solids) | Primary binder | 20–30% | Choose low-odour, coalescent-free grade |
| Ground Calcium Carbonate (GCC, d50 ~15μm) | Body filler, texture | 20–30% | Main texture-imparting material; adjust particle size for texture grade |
| Calcium Carbonate Coarse (d50 150–300μm) | Texture profile | 5–15% | Adjust percentage and grade for coarse/fine texture specification |
| TiO2 Rutile (sulphate or chloride grade) | Hiding power, whiteness | 5–10% | Reduce TiO2 and increase extenders for cost optimisation |
| Wetting & Dispersing Agent | Pigment and filler dispersion | 0.4–0.8% | Sodium polyacrylate type; critical for stability |
| Thickener (HASE or HEC) | Viscosity, sag resistance | 0.3–0.8% | HASE gives better ICI viscosity for brushability; HEC for storage stability |
| Coalescent (low-VOC, e.g. Texanol or Optifilm) | Film formation below MFT | 0.5–1.5% | Keep ≤1.5% to stay below 30 g/L VOC target |
| Biocide (in-can + dry film) | Mould and mildew prevention | 0.1–0.3% | Critical in humid GCC conditions, especially coastal KSA |
| Defoamer (mineral oil or silicone) | Foam control during mixing and application | 0.1–0.3% | Silicone defoamers risk crater formation in textured coatings — test carefully |
| Propylene Glycol (low-VOC grade) | Freeze-thaw stability, open time | 0.5–2.0% | Low vapour pressure — minimal VOC contribution |
| Ammonia solution (25%) | pH adjustment to 8.5–9.5 | 0.1–0.3% | Stabilises emulsion; prevent pH drop which causes flocculation |
VOC Calculation Guide
To verify your formulation meets the 30 g/L VOC limit for Saudi Arabia and UAE:
- List all VOC-contributing materials (solvents, coalescents, glycol ethers) with their VOC content per gram.
- Calculate total VOC mass per kg of formulation.
- Determine VOC g/L by multiplying by the coating density (typically 1.5–1.7 kg/L for textured coatings).
- Target: ≤30 g/L for interior flat, ≤150 g/L for interior semi-gloss per GSO 1914.
With the formulation above and a low-VOC coalescent at 1.0% usage, VOC content will typically fall between 15–25 g/L — comfortably within SASO limits and sufficient for LEED certification projects.
Special Considerations for GCC Application
- Surface temperature: Do not apply when surface temperature exceeds 45°C. In Saudi summer, schedule application before 8 AM or after 5 PM.
- Substrate alkalinity: Fresh cement render in Saudi Arabia can have pH above 12. Use an alkali-resistant emulsion (Veova or acrylic-based) and allow adequate cure time (28 days minimum for concrete, 7 days for modern renders).
- Dust and sand: Apply dust-resistant coatings where Shamal wind conditions cause fine dust deposit. Formulate with higher binder content (PVC below 70%) for improved surface cleanability.
Sourcing Low-VOC Coating Raw Materials from Raykem
Raykem supplies styrene-acrylic and pure acrylic emulsions, TiO2, wetting agents, and biocides to paint manufacturers across the UAE and Saudi Arabia. Our monomer and emulsion portfolio includes VAM Veova and styrene-acrylic grades suitable for low-VOC architectural coatings. All products are supplied with full SDS and COA documentation. Contact our Dubai or Riyadh team for pricing, samples, and technical support.
Need These Raw Materials for Your Process?
Raykem supplies industrial and specialty chemicals to manufacturers across the UAE, Saudi Arabia, and GCC. Get a quote within 24 hours.
Request a Quote →Frequently Asked Questions
SASO standard GSO 1914 (adopted from the Gulf Standardisation Organisation) sets VOC limits for decorative coatings. Interior matt and flat wall coatings are limited to 30 g/L VOC. Interior non-flat (eggshell, satin) coatings are limited to 150 g/L. For Vision 2030 residential projects, developers increasingly specify coatings meeting LEED or Green Star standards, which often require VOC below 50 g/L for interior walls. Always confirm the applicable specification for your project before formulating.
Yes — this is now the industry standard for residential applications in Saudi Arabia and the UAE. Water-based textured coatings using acrylic or styrene-acrylic emulsion as the binder, combined with mineral fillers (calcium carbonate, silica sand) for texture, can achieve VOC below 30 g/L while providing excellent hiding power, durability, and texture profile. The key is selecting a high-quality, low-odour coalescent and eliminating or minimising conventional solvent content.
Cracking in GCC textured coatings is most often caused by: (1) applying over a poorly prepared, dusty, or high-suction substrate without a primer; (2) applying in direct sunlight with surface temperatures above 45°C, causing too-rapid surface drying before through-drying; (3) insufficient flexibility in the binder — for exterior textured coatings in the GCC, the acrylic emulsion Tg should be below 10°C; (4) film build applied too thick in a single coat, exceeding the flexibility limits of the dry film.
